2.4/5.8 GHz
Dual Band
High Speed
1200Mbps
Support
More Users
+120
Wireless Mesh
Seamless Roaming
Easy Setup
POE Power Supply
Waterproof
Lightning Protection
Frost Resistant
Dust Resistant
Antioxidant
High Temperature
Resistant
Three Chips
Signal Stability
Wide Coverage
Omni Antennas
Designed with the full expertise of Airospot to deliver the best wireless performance.
Integrated with Airospot Cloud Services (ACS) and powered by Airospot Intelligence (AI).
| Model | Airospot AP 7200 |
|---|---|
| Hardware | DDR: 128MB; Flash: 16MB; PA chip: 2.4G KCT8227D |
| Antennas | 5dBi × 2 External Antennas |
| RF Parameters |
Transmit power: 200mW (23dBm) Receive sensitivity: -96dBm Operating frequency: 802.11ac/n/a : 5.180GHz - 5.825GHz 802.11b/g/n : 2.412GHz - 2.484GHz |
| Data Rate |
2.4GHz: 300Mbps 5GHz: 867Mbps |
| Interface |
1 × 10/100/1000Mbps WAN RJ45 Ethernet port, POE support 1 × 10/100/1000Mbps LAN RJ45 Ethernet port, POE support 1 × RESET button |
| Indicators | Power / WAN / LAN / WiFi |
| Power |
Power type: POE, supports 802.3af standard (up to 100 meters) Adapter: 48V 0.32A POE adapter (included) |
| Power Consumption | <13W |
| IP Rating | IP66 |
| MTBF | >250000H |
| Mounting Methods | Wall mount, Pole mount |
| Enclosure Materials | ABS |
| Physical Features | Size: 353 × 85 × 43.5mm |
| Environment |
Operating temperature: -10°C ~ 65°C Storage temperature: -40°C ~ 70°C Operating humidity: 10% ~ 90%RH non-condensing Storage humidity: 5% ~ 90%RH non-condensing |
| Feature | Standard Access Point | Pro Access Point |
|---|---|---|
| AiroUI | Basic | Advanced |
| Operating Modes | 4 Modes: Router, AP, Repeater, Bridge | 5 Modes: Router, AP, Repeater, Bridge, Dump AP High Performance |
| Status Dashboard | Metrics: User Count, Download/Upload, CPU/Memory Trends, Interface Status, TCP/UDP Connections |
Metrics: User Count, Download/Upload, CPU/Memory Trends, Interface Status, TCP/UDP Connections |
| Graphics & Logs | Load Graphics, Wireless Graphics, Traffic Graphics, Connections Graphics, Log System, Exportable Reports |
Load Graphics, Wireless Graphics, Traffic Graphics, Connections Graphics, Log System, Exportable Reports |
| Wireless Settings | SSID Management, WPA2 WPA3 Support, Auto Channel Selection, Wireless MAC Filtering, Radio Power Selection, Multi-SSID Support, Basic Mobility |
Advanced RF Management, WPA2 WPA3 Support, Enterprise Radius Support, Channel Management with AI Model, Wireless MAC Filtering, Power Management with AI Model: Eco Mode, Normal Mode, High Performance Mode, Sleep Mode, Multi-SSID Support, Advanced Mobility/Fast Roaming |
| Firewall | Basic Allow/Block Rules |
Advanced Firewall Rules:
DMZ, Port Forward, Port Open, DDOS Protection |
| System Settings |
Reboot / Scheduled Reboot,
Firmware Updates Backup/Restore Configuration |
Reboot / Scheduled Reboot,
Firmware Updates Backup/Restore Configuration Cloud Updates |
| Cloud Integration | - | Full Cloud Management and Centralized Monitoring |
| Upgrade Options | Manual Upgrade |
Cloud Upgrade,
Hotspot Upgrade |
| Hotspot Features | - | Captive Portal, Bandwidth Limiting, User Authentication |
| LAN/WAN Config. | VLAN Support, Basic LAN/WAN Configuration |
VLAN Support, Advanced Routing and VLAN Configurations |
| VLAN Support | Included | Included |
| QoS (Quality of Service) | Included | Included (Per User/Device Bandwidth Control) |
| Mesh Networking | Included | Included |
| Wireless MAC Filtering | Included | Included |
| LED Preset System | Color and Trigger Action Presets | Advanced Presets |
| Application | - | Automatic System Manager |
| iPerf Speed Test | Included | Included |
Router Mode
Access Point Mode
Repeater Mode
Bridge Mode
Dump AP High Performance Mode
Pole Installation
Wall-mount Installation
1x Airospot AP 7200
1x POE Power Supply
1x Ethernet Cable
1x Power Cable
2x Stainless Steel Straps
User Manual
and Warranty Certificate
AI Powered
ACS Ready
