2.4/5.8 GHz
Dual Band
High Speed
3000Mbps
Support
More Users
+220
Coverage
~600m2
Wireless Mesh
Seamless Roaming
Easy Setup
POE Power Supply
Designed with the full expertise of Airospot to deliver the best wireless performance.
Integrated with Airospot Cloud Services (ACS) and powered by Airospot Intelligence (AI).
| Model | Airospot AP 3000AX |
|---|---|
| Hardware | DDR: 128MB Flash: 16MB |
| Antenna | Built-in smart antenna system, 4×3dBi dual band antennas |
| Wireless Rate | Supports IEEE802.11b/g/n/ac/ax standards 2.4GHz: 574Mbps, 5.8GHz: 2400Mbps |
| RF Parameters |
Transmit Power: 26dBm Receiving Sensitivity: -96dBm Working Frequency: 802.11b/g/n : 2.412GHz-2.472GHz 802.11ax/ac/an/a : 5.180GHz-5.825GHz |
| Modulation Technology |
11b: DSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps 11ay OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps 11n MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM 11ac MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM 11ax MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM |
| Physical Ports |
1 × 10/100/1000Mbps WAN RJ45 Ethernet Port 1 × 10/100/1000Mbps LAN RJ45 Ethernet Port 1 × 2.5G SFP Port 1 × RESET button |
| Indicators | Power, WAN, LAN indicators |
| Power Supply | DC 12V/2A or POE 48V |
| Power Consumption | < 24W |
| Shell Material | ABS Plastic |
| Protection Grade | IP31 |
| Product Size | 220×204×6mm |
| Working Environment |
Working Temperature: -10°C~55°C Storage Temperature: -40°C~70°C Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~95%RH non-condensing |
| Feature | Standard Access Point | Pro Access Point |
|---|---|---|
| AiroUI | Basic | Advanced |
| Operating Modes | 4 Modes: Router, AP, Repeater, Bridge | 5 Modes: Router, AP, Repeater, Bridge, Dump AP High Performance |
| Status Dashboard | Metrics: User Count, Download/Upload, CPU/Memory Trends, Interface Status, TCP/UDP Connections |
Metrics: User Count, Download/Upload, CPU/Memory Trends, Interface Status, TCP/UDP Connections |
| Graphics & Logs | Load Graphics, Wireless Graphics, Traffic Graphics, Connections Graphics, Log System, Exportable Reports |
Load Graphics, Wireless Graphics, Traffic Graphics, Connections Graphics, Log System, Exportable Reports |
| Wireless Settings | SSID Management, WPA2 WPA3 Support, Auto Channel Selection, Wireless MAC Filtering, Radio Power Selection, Multi-SSID Support, Basic Mobility |
Advanced RF Management, WPA2 WPA3 Support, Enterprise Radius Support, Channel Management with AI Model, Wireless MAC Filtering, Power Management with AI Model: Eco Mode, Normal Mode, High Performance Mode, Sleep Mode, Multi-SSID Support, Advanced Mobility/Fast Roaming |
| Firewall | Basic Allow/Block Rules |
Advanced Firewall Rules:
DMZ, Port Forward, Port Open, DDOS Protection |
| System Settings |
Reboot / Scheduled Reboot,
Firmware Updates Backup/Restore Configuration |
Reboot / Scheduled Reboot,
Firmware Updates Backup/Restore Configuration Cloud Updates |
| Cloud Integration | - | Full Cloud Management and Centralized Monitoring |
| Upgrade Options | Manual Upgrade |
Cloud Upgrade,
Hotspot Upgrade |
| Hotspot Features | - | Captive Portal, Bandwidth Limiting, User Authentication |
| LAN/WAN Config. | VLAN Support, Basic LAN/WAN Configuration |
VLAN Support, Advanced Routing and VLAN Configurations |
| VLAN Support | Included | Included |
| QoS (Quality of Service) | Included | Included (Per User/Device Bandwidth Control) |
| Mesh Networking | Included | Included |
| Wireless MAC Filtering | Included | Included |
| LED Preset System | Color and Trigger Action Presets | Advanced Presets |
| Application | - | Automatic System Manager |
| iPerf Speed Test | Included | Included |
Router Mode
Access Point Mode
Repeater Mode
Bridge Mode
Dump AP High Performance Mode
Ceiling-mount Installation
Wall-mount Installation
1x Airospot AP 3000AX
1x POE Power Supply
1x Ethernet Cable
1x Power Cable
AI Powered
ACS Ready
1x User Manual and
Warranty Certificate
